The most popular sanitation bulldozer in China.
CUMMINS engine, 910 track shoe, 12cbm dozing capacity.
|
Item |
Measure |
Specification |
||
|
L× W×H（Ripper not included）,no ripper |
mm |
6290×4365×3435 |
||
|
Operating weight(Ripper not included), no ripper |
Ton |
26 |
||
|
Engine |
|
Cummins NT855-C280S10 |
||
|
Rated power |
kw/rpm |
175/1800 |
||
|
Gradeability |
° |
30 |
||
|
Blade type |
|
R-blade |
||
|
Blade length x width |
mm |
4365 ×1885 |
||
|
Dozing capacity |
M³ |
12 |
||
|
Max drop below ground of blade |
mm |
550 |
||
|
Lift height of blade |
mm |
1330 |
||
|
Number of carriers(each side) |
|
2 |
||
|
Number of track rollers(each side) |
|
8 |
||
|
Number of track shoes(each side) |
|
45 |
||
|
Width of track shoe |
mm |
910 |
||
|
Track gauge |
mm |
2250 |
||
|
Ground length and ground pressure |
mm/MPa |
3480/0.041 |
||
|
Track link pitch |
mm |
216 |
||
|
Travelling speed
|
Forward
|
D1 |
km/h
|
0-3.6 |
|
|
|
D2 |
|
0-6.5 |
|
|
|
D3 |
|
0-11.2 |
|
|
Reverse
|
R1 |
|
0-4.3 |
|
|
|
R2 |
|
0-7.7 |
|
|
|
R3 |
|
0-13.2 |
