SD22R Sanitation Bulldozer
SD22R sanitation bulldozer is developed in response to the operation demands of sanitation treatment sites in domestic cities. This product is equipped with wetland bulldozer chassis to effectively reduce the ground pressure and realize good trafficability and is especially suitable for the landfill and compaction of household garbage with high water content.
Engine power/speed:162kw/1800rpm
●The high capacity sanitation blade and mud scraper are equipped to effectively improve the working efficiency. The unique heightened part on the top of the blade can prevent the ingress of handled material into rear side of blade.
●The special equipment, including high-mount warning lamp, reversing alarm, camera, and LCD display, are equipped to remarkably improve the operation safety in the working sites.
●The central lubrication, central pressure measurement, and automatic track tension systems are equipped to ease the site checking and maintenance of the equipment.
|
Length × width × height (mm) (excluding ripper) |
6225×4365×3782 | Operating weight(t)(excluding ripper) | 26 |
| Engine model | WD12G240E206/ NT855-C280S10 | Net power/rated speed (kW/rpm) | 162/1800 |
| Ground pressure(Mpa) | 0.041 | Blade type | Sanitation blade |
| Blade capacity(m3) | 12 |
|
|
